Victron Phoenix 48/3000

SKU: PIN483020000

Availability: In stock

€1,158.00

* Required Fields

Victron

Worldwide delivery




Product Description
Details

Victron Phoenix 48/3000 sine wave inverter - 230V

Pure sine wave output, high peak power and high efficiency.
Combined high frequency and line frequency technologies ensure the best of both worlds.

SinusMax - Superior engineering
Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.

Parallel and 3-phase operation capability
Up to 6 Phoenix Inverters can operate in parallel to achieve higher power output. Six 24V 5000VA units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

SinusMax - Superior engineering
Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The  design  criteria  have  been  to  produce  a  true  sine  wave  inverter  with  optimized efficiency  but  without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem-free, to any load.

Extra start-up power
A  unique  feature  of  the  SinusMax technology  is  very  high  start-up  power.  Conventional  high  frequency technology does not offer such extreme performance. Phoenix Inverters, however, are well suited to power up difficult loads such as refrigeration compressors, electric motors and similar appliances.

Virtually unlimited power thanks to parallel and 3-phase operation capability
Up  to  6  units  inverters  can  operate  in  parallel  to  achieve  higher  power  output.  Six  24/5000  units,  for  example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

To transfer the load to another AC source: the automatic transfer switch
If  an  automatic  transfer  switch  is  required  we  recommend  using  the  MultiPlus  inverter/charger  instead.  The switch is included in these products and the charger function of the MultiPlus can be disabled. Computers and other  electronic  equipment  will  continue  to  operate  without  disruption  because  the  MultiPlus  features  a  very short switchover time (less than 20 milliseconds).

Computer interface
These larger Phoenix inverter models come with a VE.Bus port. All you need to connect to your PC is our MK3-USB  VE.Bus to USB interface (see under accessories). Together with our VEConfigure software, which can be downloaded free of charge from our website, all parameters of the inverters can be customized. This includes output voltage and frequency, overand  under voltage settings  and  programming  the  relay.  This  relay  can  for  example  be  used  to  signal  several alarm conditions, or to start a generator. The inverters can also be connected to a GX device (eg Cerbo GX) for monitoring and control.
